Durable industrial-grade plug and socket set designed for heavy-duty applications in demanding environments. Constructed with brass contacts and nylon PA housing for superior conductivity and impact resistance. Available in 16A, 32A, 63A, and 125A configurations to support single-phase (220V 50/60Hz) and three-phase power systems. Features IP44 waterproof protection for reliable performance in wet or dusty conditions, with a wide operating temperature range of -25°C to 80°C. Multiple outlet options include 3-pin (2P+E), 4-pin (3P+E), and 5-pin (3P+E+N) configurations, compatible with 3-5 outlet setups. Ideal for construction sites, manufacturing plants, and industrial machinery requiring robust electrical connections. Customizable specifications for current, voltage, and clock settings to meet project-specific requirements. Meets strict safety standards with grounding support and flame-retardant materials.
Industry-specific attributes
| Rated Voltage | 220V |
| Rated Current | 16A, 32A, 63A, 125A |
| Application | Industrial |
| WIFI | NO |
Other attributes
| Place of Origin | Zhejiang, China |
| Model Number | ES-PL01-0083 |
| AC outlets quantity | 3 Outlets, 4 Outlets, 5 Outlets |
| Material | Brass, Nylon |
| Grounding | Other |
| IP level | Ip44 |
| Product name | Industrial connector plug |
| Frequency | 50/60Hz |
| Temperature Range | -25℃~80℃ |
| PIN | 3Pin(2P+E) / 4Pin(3P+E) / 5Pin(3P+E+N) |
| Housing Material | Nylon PA |
| Contact Material | Copper |
| Customized | Yes |
| Customized support | Current,Voltage,Clock |
Lead time
| Quantity (pieces/sets) | 1 – 100 | 101 – 500 | > 500 |
|---|---|---|---|
| Lead time (days) | 15 | 25 | To be negotiated |
